山東空壓機高溫停機的原因是什么？

  夏季天氣炎熱，特別是在高溫中不停工作的山東空壓機，山東空壓機在高溫停機應該如何檢查處理，這是怎樣造成的，我們?cè)撛鯓尤ヌ幚?，下面清越?jié)能為您排憂解難。

In the summer of Shandong, the air compressor should be shut down in order to solve the problem of high temperature.

一、檢查空壓機的冷卻器，如果是風冷方式的冷卻器，就檢查灰塵是否過多了，過多容易導致通風不良，使空壓機設備達不到足夠的散熱，容易出現高溫的情況；水冷的冷卻器就檢查有沒有過多水垢產生了堵塞，帶不走油點溫度，達不到散熱效果。

1、 Check the cooler of the air compressor. If the cooler is air-cooled, check whether there is too much dust. If too much dust is easy to lead to poor ventilation, the air compressor equipment can not achieve enough heat dissipation, and high temperature is easy to occur; the water-cooled cooler will check whether there is too much scale blocking, and the oil point temperature can not be carried away, which can not achieve the cooling effect.

二、檢查空壓機機油、油位是否已經少于機油窺視鏡最低限度。機油過少的情況下，空壓機在整個運行過程中是得不到足夠的冷卻和潤滑作用的。

2、 Check whether the oil and oil level of air compressor is less than the minimum limit of oil sight glass. Under the condition of too little oil, the air compressor can not get enough cooling and lubrication in the whole operation process.

三、要做好溫控閥的檢查，溫控閥它好比一個四通閥，在溫度低的時候機油循環是從油分離器直接通到主機頭里潤滑散熱，當機油循環中溫度一般達到80-88度左右的時候溫控閥會漸漸打開讓油分離器的機油通過冷卻器冷卻后再送到主機里達到冷卻循環的作用。

3、 To check the temperature control valve, the temperature control valve is like a four-way valve. When the temperature is low, the oil circulation is directly from the oil separator to the main engine head for lubrication and heat dissipation. When the oil circulation temperature generally reaches about 80-88 degrees, the temperature control valve will gradually open to let the oil from the oil separator be cooled by the cooler and then sent to the main engine to achieve cooling cycle.

四、要檢查斷油閥和油過濾，油過濾堵塞會導致主機頭進油量過少，一般油過濾是周期性的必須更換。而斷油閥沒有完全打開也會導致進油量過少都會讓主機頭逐漸升溫，直到報警停機為止。

4、 To check the oil cut-off valve and oil filtration, the blockage of the oil filter will lead to too little oil into the main engine head. Generally, the oil filtration is periodic and must be replaced. If the oil cut-off valve is not fully opened, it will cause too little oil into the engine head, which will make the engine head gradually warm up until the alarm stops.

五、要檢查溫度傳感器和溫度開關，這是很重要的一個檢查，溫度傳感器，是一個熱電阻，起到一個探測信號的作用，把信號傳到電腦主控器里邊。如果傳感器故障，就會出現探測的溫度不準確，還有傳感器的線接觸不良等都會引起主控報警停機的。

5、 To check the temperature sensor and temperature switch, this is a very important check. The temperature sensor, which is a thermal resistance, plays a role in detecting the signal and transmits the signal to the main controller of the computer. If the sensor fails, the temperature detected will not be accurate, and the sensor line contact is not good, which will cause the master control alarm and shutdown.

當然這五個檢查是在出現空壓機高溫時候比較容易出現的情況，也不排除其他可能，如是否機頭的異響，某個部件損壞，空壓機起到自身的保護作用產生的預警，所以停機了。

Of course, these five inspections are relatively easy to occur when the air compressor is in high temperature, and other possibilities are not ruled out, such as whether the abnormal noise of the machine head, the damage of a certain part, the air compressor plays its own protective role, and the early warning is generated, so it is shut down.
