山東干燥機是如何提高工作效率的？

干燥機的型號許多，可以選擇烘干的物料范圍也很廣，那么究竟哪種類型的山東干燥機適合什么樣的物料呢？對于客戶來說是個盲區?？吹竭@里，相信大家一定急著想知道具體的節能辦法，下面就給大家簡單的說一下怎么選擇適合自己的干燥機設備。干燥機類型許多，看自己的工作適合哪種型號，在選擇時一定要注意其型號，對物料有何要求，這樣選型才會符合自己工作的需要，也能提高生產力，主要還是要注意以下幾點：

There are many types of dryers, and the range of materials that can be selected for drying is also very wide. So which type of dryer in Shandong is suitable for what kind of materials? It's a blind spot for customers. See here, I believe you must be anxious to know the specific energy-saving methods, the following is a simple description of how to choose the dryer suitable for their own equipment. There are many types of dryers. It is necessary to pay attention to the model and material requirements when selecting the dryer according to the type of dryer. In this way, the type selection can meet the needs of your own work and improve the productivity. The following points should be paid attention to:

一、漆銹的預防：烘干機軸承在裝到轉子上做動平衡時很等閑將動平衡時產生的鐵屑進入軸承內部，因此好是裝軸承前做動平衡。有一些廠家為了裝配方便，裝配時在軸承室內涂上一些油或油脂起潤滑效果，但往往操作人員很難將量控制好，如果油或油脂在軸承室內積留較多，在軸承動彈時很等閑沿著軸進入軸承內部。軸承室好是不要涂油或油脂，如非涂不可則要控制不得在軸承室內有積留。

1、 Prevention of paint rust: when the bearing of dryer is installed on the rotor for dynamic balance, the iron filings generated during dynamic balance will enter into the bearing, so it is better to make dynamic balance before installing the bearing. In order to facilitate the assembly, some manufacturers apply some oil or grease in the bearing chamber for lubrication effect. However, it is difficult for the operator to control the quantity well. If the oil or grease accumulates in the bearing chamber, it is easy to enter the bearing along the shaft when the bearing moves. Do not apply oil or grease to the bearing chamber. If it is necessary to do so, it should be controlled and there should be no accumulation in the bearing chamber.

二、裝配異物的防止：因為干燥機軸承是高精度產品，如裝配不當很等閑對軸承溝道造成損傷，導致軸承損壞。軸承在裝配時應有專用的模具，不能隨意敲打，在壓入軸時只能小圈受力，壓大圈時只能大圈受力。裝配時要求采用氣壓或液壓，在壓裝時上下模要外于水平狀態，如有傾斜會導致軸承溝道因受力損壞，而使軸承產生導響。

2、 Prevention of assembly foreign matters: because the dryer bearing is a high-precision product, improper assembly will damage the bearing raceway, resulting in bearing damage. The bearing should have a special mold during assembly, which can not be knocked at will. When pressing into the shaft, only a small circle can be stressed, and when pressing a large ring, only a large ring can be stressed. During assembly, pneumatic or hydraulic pressure is required. When pressing, the upper and lower dies should be out of horizontal state. If there is inclination, the bearing raceway will be damaged due to stress, and the bearing will produce guiding sound.

三、軸承的裝配方式：軸承壓入軸承后應動彈靈活無阻滯感。如有明顯動彈不靈活，則表明軸的尺寸太大了，公差要下調。如軸承壓入軸后用手動彈有明顯“沙沙”感，則可能是軸的公差太大或軸的圓度不好。所以在控制好軸和軸承室公差時也要控制好圓度，目前國內許多廠家只對公差進行控制，沒有對圓度進行控制。

3、 Assembly method of bearing: the bearing shall be flexible and free of blocking after being pressed into the bearing. If there is obvious inflexibility, it indicates that the size of the shaft is too large and the tolerance should be reduced. If the bearing pressure into the shaft with manual spring has obvious "rusty" feeling, it may be that the tolerance of the shaft is too large or the roundness of the shaft is not good. Therefore, roundness should also be controlled when the tolerance of shaft and bearing chamber is well controlled. At present, many domestic manufacturers only control the tolerance, but not the roundness.

四、烘干機軸和軸承室公差的選擇與控制：軸承的壽命是與制造、裝配、使用都緊密相關的，須在每個環節都做好，才能使軸承處于可靠的運轉狀態，從而延長軸承的使用壽命。

4、 Selection and control of tolerances for shaft and bearing chamber of dryer: the service life of bearing is closely related to manufacture, assembly and use. Only by doing well in every link can the bearing be in reliable operation state and prolong the service life of bearing.

漆銹的特征是多發在封密式的電機，電機在裝配時聲音很好，但在倉庫內放了一些時間后，電機異響變的很大，拆下軸承有嚴重生銹現象。

The characteristic of paint rust is that it often occurs in sealed motor. The sound of motor is very good during assembly. However, after being put in the warehouse for some time, the abnormal noise of motor becomes very big, and the bearing is seriously rusted when the bearing is removed.
