In modern enterprises, the use of compressed air is more and more common. The common compressed air dryers are adsorption dryer and freezing dryer. What is the difference between freeze dryer and adsorption dryer?

1工作原理上的不同

1. Different working principles

冷干機是根據冷凍除 濕原理，將來自上游的飽和壓縮空氣通過與冷媒的熱交換冷 卻到一定的溫度，凝析出大量的液態水，經氣液分離器分離后自動排出機外，從而達到除水干燥的目的。吸干機則是根據變壓吸附的原理，將來自上游的飽和壓縮空氣在一定的壓力下經過與干燥劑的接觸，將絕大部分的水份吸附在干燥劑里，干燥空氣進入下游工作，從而達到深 度干燥的目的。

According to the principle of freezing dehumidification, the chiller cools the saturated compressed air from upstream to a certain temperature through heat exchange with refrigerant, condenses out a large amount of liquid water, and automatically discharges it out of the chiller after separation by gas-liquid separator, so as to achieve the purpose of water removal and drying. Suction dryer is based on the principle of pressure swing adsorption, will come from the upstream saturated compressed air under a certain pressure through contact with the desiccant, the vast majority of moisture adsorption in the desiccant, dry air into the downstream work, so as to achieve the purpose of deep drying.

2除水效果上的不同

2. Different water removal effect

冷干機因?yàn)槭艿狡湓淼闹萍s，如果溫度太低的話會出現結冰現象，所以其的溫度通常在2~10℃。吸干機則因?yàn)闊o須通過溫度變化，而干燥劑（氧化鋁）則又可以進行深 度干燥，所以通常其出口的溫度可以達到-20℃以下，也就是說可以達到深 度干燥。

Because of its principle, if the temperature is too low, there will be icing phenomenon, so its temperature is usually 2 ~ 10 ℃. The suction dryer does not need to change the temperature, and the desiccant (alumina) can carry out deep drying, so the outlet temperature of the suction dryer can reach below - 20 ℃, that is to say, it can achieve deep drying.

3能 量損耗上的不同

3. Difference in energy consumption

對于冷干機來說，因?yàn)橐ㄟ^冷媒壓縮作功方可達到冷 卻的目的，所以在電源功率上會偏高。而吸干機因?yàn)橹灰ㄟ^電控箱對閥門進行控制而已，所以通常用電功率只有幾十瓦左右，也就是說不會有什么電量上的損耗。

For the cold dryer, because the purpose of cooling can only be achieved through refrigerant compression, so the power supply will be high. As long as the valve is controlled by the electric control box, the power consumption of the suction dryer is usually only about tens of watts, that is to say, there will be no power loss.

4氣量損耗的不同

4. Difference of gas loss

因?yàn)槔涓蓹C(jī)是通過變溫來達到除水的目的，水份又是通過自動排水器排出機外，所以沒有氣量的損耗。而吸干機則因?yàn)楦稍飫┰谖柡秃笮枰?生，因些需要有12-15%左右的再 生氣損耗。

Because the cold dryer is to achieve the purpose of water removal by changing the temperature, and the water is discharged from the machine through the automatic drainer, so there is no loss of air volume. The dryer needs to be regenerated after water absorption saturation, so it needs about 12-15% regeneration gas loss.

5故障率的不同

5 different failure rates

因?yàn)槔涓蓹C(jī)的冷媒系統和空氣系統包括電氣部分都相對復雜，而吸干機則只有閥門因要頻繁動作而具有故障可能，所以在通常情況下吸干機的故障率要低過冷干機。

Because the refrigerant system and air system of the dryer, including the electrical part, are relatively complex, and only the valve of the dryer has the possibility of failure due to frequent action, so in general, the failure rate of the dryer is lower than that of the supercooled dryer.

總的說來，吸干機無論在穩定性還是在效果上都要優于冷干機，只是因?yàn)橐獡p耗一定量的再 生氣，所在我們一般要客戶權衡利弊后作出選擇。不過現在已有越來越多的廠家選擇吸干機，應該說這在逐漸成為一種趨勢

Generally speaking, the suction dryer is better than the cold dryer in terms of stability and effect, just because it needs to consume a certain amount of regeneration gas, so we usually ask customers to weigh the pros and cons before making a choice. But now there are more and more manufacturers choose suction dryer, it should be said that this is gradually becoming a trend
