Air compressor, lubricating oil, action screw, air compressor lubricating oil system ① during the working process of lubricating oil system, lubricating oil is pressed into the oiler under the action of gas pressure in the oil-gas barrel. After the lubricating oil is added, the impurity particles are removed through the oil filter, and then divided into two routes. One route is sprayed into the compression chamber at the lower end of the machine body to compress air, and the other route is connected to both ends of the machine body to lubricate the bearing group and transmission gear, and then the lubricating oil of each part is discharged with the compressed gas in the compression chamber.

與油混合的壓縮氣體進入油氣桶，分離一大部分的油，其余的含油霧氣體再經過油細分離器，濾去剩余的油，經保壓閥進入后部器，即回送至使用的系統中。②潤滑油系統的油路組件．油器油器與氣體接觸后，器的方式相同，有風冷與水冷二種方式。若環境狀況不佳，則風冷式器的翅片易受灰塵覆蓋而影響，排氣溫度會過高而致跳機。

The compressed gas mixed with oil enters the oil-gas drum to separate a large part of the oil. The remaining oil mist gas passes through the oil fine separator to filter the remaining oil, and enters the rear filter through the pressure retaining valve, that is, it is returned to the used system. ② The oil circuit components of the lubricating oil system. After the oil cooler contacts with the gas, the way of the oil cooler is the same, including air cooling and water cooling. If the environmental condition is poor, the fins of the air-cooled cooler are easily affected by dust coverage, and the exhaust temperature will be too high to trip.

因此，應定期用壓縮氣體將翅片表面的灰塵吹掉，若無法吹干凈則必須以溶劑來清洗，務必保持器散熱表面干凈。管殼式器在堵塞時，必須用化學清洗浸泡，且以機械清洗的高壓水將堵塞在換熱管內的結垢清除，務必確保完全清洗干凈。．油過濾器油過濾器是一種紙質的過濾器，其能是除去油中雜質如金屬微粒、油雜質及油沉淀物等。

Therefore, the dust on the fin surface should be blown off regularly with compressed gas. If it cannot be blown clean, it must be cleaned with solvent. Be sure to keep the heat sink surface clean. When the shell and tube heat exchanger is blocked, it must be soaked with chemical cleaning, and the scale blocked in the heat exchange tube must be removed with mechanically cleaned high-pressure water. Make sure it is completely cleaned Oil filter oil filter is a paper filter, which can remove impurities in oil, such as metal particles, oil impurities and oil sediment.

過濾精度在～之間，對軸承及轉子有完善的保護作用，是否應當更換油過濾器可由其壓差指示和運轉時間來判斷，如果壓差指示燈亮，表示油過濾器阻塞，必須更換。

The filtering accuracy is between ~, which has perfect protection for the bearing and rotor. Whether the oil filter should be replaced can be judged by its differential pressure indication and operation time. If the differential pressure indicator is on, it indicates that the oil filter is blocked and must be replaced.

新機一次運轉之后即需更換油及油過濾器，爾后則依據壓差指示燈或運轉時間而定是否更換。若油過濾器壓差大而沒更換，可能導致進油量不足，造成排氣溫度過高聯鎖停車，同時因油量不足會影響到軸承壽命。

The oil and oil filter shall be replaced immediately after the new machine runs for one time, and then whether to replace it shall be determined according to the differential pressure indicator or operation time. If the pressure difference of the oil filter is large and it is not replaced, it may lead to insufficient oil inlet, high exhaust temperature and interlocking shutdown. At the same time, insufficient oil will affect the service life of the bearing.
